Teletek electronics BRAVO - 4. Hardware Settings

BRAVO – Wireless Alarm Control Panel
19
4. Hardware Settings
4.1. Dip-switches
Use the dip-switches to set some additional settings
according the configuration and operation of the system.
Every dip-switch has two positions ON and OFF used to
set certain functionality.
Use a small suitable tool to set the position of the dip-
switch.
ATTENTION: The numbers of the dip-switches
are described according their location on the
panel’s PCB.
The dip-switches order and their functionality are
described as:
No
Description
Position
ON
OFF
8
Power RF (Increased
sensitivity of the control panel)


7
Not used
-
-
6
Communication type
All
Altern.
5
Zone types
(see item 4.2)
Config.
2
Config.
1
4
Sound signalization on ARM/
DISARM
(for the built-in sounder only)


3
Clear the bypassed zones on
DISARM


2
LED Indication – panel
(in ARMING)


1
LED Indication - devices


- Enabled;  - Disabled
Every change of the position of the dip-switches is
instant and does not require resetting of the panel
for confirmation of the new settings.
All dip-switches are set in OFF position from the
manufacturer after the production.
The setting of the dip-switches does not change
after full hardware reset of the panel.
The current position of the hardware dip-switches
can be checked via the software applications
ProsTE and AjaxWEB.
4.2. Type configurations of the zones
The installer can choose between two basic
configurations for the zone types with setting the
position of dip-switch 5.
The zone type description is as follow:
 Entry-Exit – Provides time to arm and disarm the
site. After arming, the detector, which was triggered
off in this zone, will not sound an alarm until the
programmed EXIT TIME expires.
When the entry-exit zone is opened in armed mode
an ENTRY TIME starts running during which the
user must disarm the system. When the entry time
expires and the system is not disarmed the sounders
will alarm for burglary not authorized entry.
 Follow – An alarm zone which is active only when
the site is armed. The zone operates
instantaneously. Activating the zone during entry or
exit time does not cause an alarm event.
 Instant - An alarm zone which is active only when
the site is armed. The zone operates
instantaneously. Activating the zone during entry or
exit time causes an alarm event.
 Fire – 24-hour fire zone. All wireless fire detectors
are automatically attached to this type of zone during
the enrollment. The zone operates instantaneously
when a fire detector is activated as the sounders are
activated and FIRE alarm message is sent via the
available communication channels.
 24-hour security zone. All wireless flood detectors
are automatically attached to this type of zone during
the enrollment. The zone operates instantaneously
when a flood detector is activated as FLOOD alarm
message is sent via the available communication
channels.
The description of the zone configurations:
Zone No
Configuration
Type of the
Device
1
2
1
Entry-Exit
Instant
MC or PIR
2*
Entry-Exit
Instant
MC
Follow
PIR
3-16*
Instant, fire
or 24-hour
security
zone
Instant, fire
or 24-hour
security
zone
Every device
* Depends on the type of the enrolled detector to the
zone.
HARDWARE SETTINGS
