9.3. Charging a battery pack
Connect the wall plug battery charger to the socket (6)
of the battery pack (refer to Figure 8.3). The Power
LED lights up (refer to Table 9.3).
During the charge, the charging LED is lit, and the
capacity indicator shows the capacity of the battery
pack. The top LED segment of the capacity indicator
flashes (e.g.: if state of charge = 36% then LED2 will
blink). Pushing the test button has no effect when the
charge is in progress.
When the charging is completed, the charging LED (5)
and the capacity indicator (2) switch off. Push the test
button (1) to check the capacity of the battery pack.
The LED segment indicator will show the capacity of
the battery for a few seconds, then the status of the
battery (refer to chapter 8.4 ‘Installation’) will be
indicated.
Table 9.3: Charging status indicators
Status
Power
LED
(yellow)
Capacity
indicator
Charge is in
progress
On On
On
(top LED
segment
flashes)
Charge is
completed
On Off
Off
(Push test
button to
check the
capacity and
the status)
Charger is
disconnected
or not
powered
Off Off
Off
(Push test
button to
check the
capacity and
the status)
Note:
A battery pack can be charged
separately, or when inserted in a
wireless unit.
Note:
The wall plug charger can be used to
power a Confidea wireless unit. In
this case the battery pack needs to be
installed in the unit.
