12.2.2. Quality 2.4 GHz ISM
Channel Quality
On this webpage the expected quality for each
possible RF channel in the 2.4GHz ISM band can be
monitored.
This visualization of channel availability and quality
helps to select a fixed RF channel in case the system
is set not to work in automatic mode.
See also notes on Page 54
12.2.3. Quality 5.15 – 5.35 GHz
On this webpage the expected quality for each
possible RF channel in the 5.15-5.35 GHz band can be
monitored.
This visualization of channel availability and quality
helps to select a fixed RF channel in case the system
is set not to work in automatic mode.
12.2.4. Quality 5.47 – 5.725 GHz
On this webpage the expected quality for each
possible RF channel in the 5.47-5.725 GHz band can
be monitored.
This visualization of channel availability and quality
helps to select a fixed RF channel in case the system
is set not to work in automatic mode.
12.2.5. Quality 5.8 GHz ISM
On this webpage the expected quality for each
possible RF channel in the 5.8 GHz ISM band can be
monitored.
This visualization of channel availability and quality
helps to select a fixed RF channel in case the system
is set not to work in automatic mode.
Note:
The channel availability is visualized using
colors:
• A full GREEN bar indicates the
channel is available 100% of the
time. This channel is thus safe to use.
• A full RED bar indicates the channel
is fully occupied by other radio
devices. This channel should not be
used to operate the wireless
Confidea system.
• The more activity on a channel, the
more the corresponding bar will
color RED, and thus the more likely
interference will occur with other
systems.
Note:
From time to time, the Confidea wireless
system will also measure its own activity
in the channel on which it is currently
operating.
This results in a RED indication on the
corresponding bar graph, but does not
affect the reliable operation of the
system.
