59
Step 2 Configure the switch.
Create IEEE 802.1q VLANs described in the following table on the switch.
Port Connected To Accessible VLAN ID Port Type PVID
AP
1, 2, 3, 4
Trunk
1
Internal server
3, 4
Trunk
1
Router
2, 4
Trunk
1
Retain the default settings of other ports. For details, refer to the user guide for the switch.
Step 3 Configure the router and the internal server.
To ensure a normal internet access for wireless clients connected to the AP, the router and internal
server must support the QVLAN function and need to be configured. See the following table.
Router:
Port Connected To Accessible VLAN ID Port Type PVID
Switch
2, 4
Trunk
1
Internal server:
Port Connected To Accessible VLAN ID Port Type PVID
Switch
3, 4
Trunk
1
For configuration details, refer to the user guides of your router and internal server.
---- End
Verification
Wireless devices connected to the SSID internet can access only the internet. Wireless devices
connected to the SSID oa can access only the intranet. Wireless devices connected to the SSID VIP
can access both the internet and the intranet.
