Tenda O1 User Manual

106
Step 13 In the Windows Security dialog box that appears, enter the user name and password set on the
RADIUS server and click OK.
------End
Verification
Wireless devices can connect to the wireless network hotspot.
7.2 Advanced
7.2.1 Overview
This module enables you to adjust the wireless performance. You are recommended to configure it under the
guide of a professional.
Changing Advanced Settings
It is recommended that you change the settings only under the instruction of professional personnel,
so as to prevent decreasing the wireless performance of the CPE.
Step 1 Choose Wireless > Advanced.
Step 2 Change the parameter settings as required.
Step 3 Click Save.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
