Tenda O1 User Manual

87
Name
Description
Encryption Algorithm
It specifies the encryption algorithm corresponding to the selected security mode. The available
options include AES, TKIP, and TKIP&AES.
AES: It indicates the Advanced Encryption Standard.
TKIP: It indicates the Temporal Key Integrity Protocol.
TKIP&AES: It indicates that both TKIP and AES encryption algorithms are supported. Wireless
clients can connect to the wireless network corresponding to the selected SSID using TKIP or AES.
Key Update Interval
It specifies the automatic update interval of a WPA key for data encryption. A shorter interval
results in higher data security.
The value 0 indicates that a WAP key is not updated.
7.1.3 Examples of Configuring Basic Settings
Setting up a Non-encrypted Wireless Network
Networking Requirement
A residential community uses the CPEs to deploy its network for video surveillance. It requires that the SSID is
FREE and there is no WiFi password.
Configuration Procedure
Assume that the second SSID of the AP, the WPA2-PSK security mode, and AES encryption algorithm are used.
Step 1 Choose Wireless > Basic.
Step 2 Enable the wireless function.
Step 3 Change the value of the SSID text box to FREE.
Step 4 Set Security Mode to None.
Step 5 Click Save.
SSID: FREE

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
