Tenda O1 User Manual

22
3.2 Logout
You can click Logout on the upper-right corner of the web UI to logout. When you close the web browser, the
system logs you out as well.
If you log in to the web UI of the CPE and perform no operation within the login timeout interval (default: 5
minutes), the CPE logs you out.
3.3 Web UI Layout
The web UI of the CPE is composed of 4 parts, including the level-1 navigation tree, level-2 navigation tree, tab
page area, and configuration area. See the following figure.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
