20
3 Web UI
3.1 Login
Step 1 Connect the computer to the device.
1. Uncover the housing of the device.
2. Use an Ethernet cable to connect the PoE/LAN/WAN port of the device to the PoE port of the PoE
injector.
3. Use the included power adapter to connect the PoE injector to a power socket. The LAN/WAN LED
indicator of the device lights up.
4. Use an Ethernet cable to connect your computer to the LAN port of the PoE injector.
Step 2 Start a web browser on your computer, and visit 192.168.2.1. Enter your user name and password
(default: admin), and click Login.

Table of Contents

Other manuals for Tenda O1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda O1 and is the answer not in the manual?

Tenda O1 Specifications

General IconGeneral
5 GHzNo
Bandwidth2.4 GHz
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate300 Mbit/s
PlacementWall
CertificationFCC/CE/RoHS
Product colorWhite
LED indicatorsLAN, PoE, WLAN
International Protection (IP) codeIP64
Output voltage9 - 12 V
Power consumption (max)2.6 W
Security algorithmsWEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports1
Antenna featuresIntegrated antenna
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-30 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth67.5 mm
Width80 mm
Height190.35 mm
