Tenda O1 User Manual

12
2.2 CCTV Surveillance
To ensure the safety of employees and property, a video surveillance system needs to be installed in a building
site.
2.2.1 Solution
Tenda CPE can address this requirement.
O3 is used as an example to illustrate the installation procedure. The installation procedure of O1 is similar.
2.2.2 Setting up the CPEs
At least two CPEs are required for bridging.
Method 1: Automatic Bridging (Recommended)
Step 1 Place the two CPEs next to each other, see the following figure.
Step 2 Remove the housing of each CPE, and use the included PoE injectors to power them on.
Wait until the LAN/WAN LED indicators of the CPEs light up.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
