Tenda O1 User Manual

63
Name
Description
CCQ
It specifies the connection quality of the corresponding client. Higher percentage indicates better
connection quality.
Connection Duration
It specifies the time that has elapsed since the wireless client is connected to the wireless
network of the CPE.
5.3.3 Upstream AP
This function is available only when the CPE works in Client, Universal Repeater, or WISP mode.
Parameters Description
Name
Description
IP Address
It specifies the IP address of the upstream device.
MAC Address
It specifies the MAC address of the upstream device.
Signal/Noise
It specifies the WiFi signal strength and electromagnet interference signal strength of the
upstream device.
Transmit/Receive
It specifies the transmitting and receiving rate of the upstream device.
CCQ
It specifies the connection quality of the upstream device. Higher percentage indicates better
connection quality.
Connection Duration
It specifies the time that has elapsed since this CPE bridges to the upstream device.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
