Tenda O1 User Manual

146
Configuration Procedure
Step 1 Choose Advanced > Network Service.
Step 2 Enable the DMZ Host function.
Step 3 Enter the IP address of the computer to be set to DMZ host, which is 192.168.2.100 in this example.
Step 4 Click Save on the bottom of this page.
----End
Verification
Enter Protocol name://WAN port IP address:port number in the address bar of a web browser on a computer
over the internet to access the resources on the web server. In this example, enter http://202.105.106.55:80.
If the DDNS function is enabled, you can visit an address in the form of Protocol name://domain name:port
number.
If internet users still cannot visit the web server in LAN after the configuration, try the following
solutions:

Ensure that the WAN IP address of the CPE is a public IP address.

Security software, antivirus software, and the built-in OS firewall of the computer may cause the function failures.
Disable them and try again.

Manually set an IP address and related parameters for the web server to avoid the service disconnection caused by
the dynamic IP address.
8.6.8 Telnet Service
With this function enabled, you can check the information of the CPE via Telnet.
Choose Advanced > Network Service to enter the page. By default, the function is disabled.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
