Tenda O1 User Manual

162
Parameters
O1
O3
Country/Region
China
SSID
Tenda_XXXXXX, and XXXXXX is the last six characters of the
LAN MAC address of the CPE
Broadcast SSID
Enable
Network Mode
11b/g/n
Channel
Auto
Transmit Power
20 dBm
29 dBm
Channel Bandwidth
20 MHz
Auto
Extension Channel
/
Auto
Transmit Rate
Auto
Auto
Security Mode
None
Isolate Client
Disable
Max. Number of Clients
16
48
Wireless-Advanced
WMM
Enable
APSD
Disable
Minimum RSSI Threshold
Disable
Preamble
Long Preamble
Signal Transmission
/
Coverage-oriented
Signal Reception Level
Level 4
Auto
Transmission Distance
/
3 km
Beacon Interval
100ms
Fragment Threshold
2346
RTS Threshold
2347
DTIM Interval
1
1
Signal LED1 Threshold
-90 dBm
-90 dBm
Signal LED2 Threshold
-80 dBm
-80 dBm
Signal LED3 Threshold
-70 dBm
-70 dBm
Wireless –Access Control
Disable

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
