Tenda O1 User Manual

30
Name
Description
function of this device, the peer AP is required to support WDS function, and use the same radio
band as that of this device.
P2MP mode: this device connects 2 or more (this device supports 4 at most) wired networks with a
wireless link, but cannot be connected with wireless clients. P2MP mode is used to achieve
communication between multiple offices of an enterprise in a city.
Router mode: in this mode, the PoE LAN/WAN port works as the WAN port and is used to connect to
a modem for internet access.
Transparent Bridge
With the function enabled, IP cameras can be discovered by the NVR.
Upstream AP
It specifies the wireless network name (SSID) of the upstream AP.
Channel
It specifies the operating channel of the WiFi network to be bridged. It will be automatically
populated when you select an SSID to bridge.
Security Mode
It specifies the security mode of the WiFi network to be bridged. It will be automatically populated
when you select an SSID to bridge. If the WiFi network to be bridged has a WiFi password, you need
to enter the password manually.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
