Tenda O1 User Manual

54
Parameters Description
Name
Description
Working Modes
It specifies the working mode of the CPE.
AP mode: in this mode, the device creates a wireless network based on the current wired network.
Client mode: in this mode, the device works as a wireless adapter to connect to the wireless network
of upstream AP, and does not provide wireless access point.
Universal Repeater mode: in this mode, this device expands your WiFi network for broader network
coverage.
Advantage of Universal Repeater compared with Repeater mode: This mode does not require that
the upstream AP supports WDS function.
WISP mode: connect to an access point provided by ISP in wireless manner.
Repeater mode: the CPE connects 2 or more (this device supports 4 at most) wired networks with a
wireless link, and can be connected with both wired and wireless clients. To use the Repeater
function of this device, the peer AP is required to support WDS function, and use the same radio
band as that of this device.
P2MP mode: this device connects 2 or more (this device supports 4 at most) wired networks with a
wireless link, but cannot be connected with wireless clients. P2MP mode is used to achieve
communication between multiple offices of an enterprise in a city.
Router mode: in this mode, the PoE LAN/WAN port works as the WAN port and is used to connect to
a modem for internet access.
Peer AP
It specifies the wireless network name (SSID) of the peer AP.
Channel
It specifies the operating channel of the WiFi network to be bridged. It will be automatically
populated when you select an SSID to bridge.
Security Mode
It specifies the security mode of the WiFi network to be bridged. It will be automatically populated
when you select an SSID to bridge.
The P2MP mode only supports WEP and None security modes.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
