Tenda O1 User Manual

59
Name
Description
WLAN MAC Address
It specifies the MAC address of the wireless network of this device.
PoE LAN/LAN Speed
It specifies the connection status of PoE LAN/WAN and LAN ports. It includes connection rate
and duplex mode.
LAN IP Address
It specifies the IP address (also named management IP address) of this device. By default, it is
192.168.2.1. You can access the web UI of this device using this IP address.
If the CPE is set to WISP or Router mode, the system status is shown as follows:
Parameters Description
Name
Description
Connection Status
It specifies the connection status of WAN port of this device in WISP or Router mode.
Connection Type
It specifies the internet connection type of this device in WISP or Router mode.
WAN IP Address
It specifies the IP address of WAN port of this device in WISP or Router mode.
Default Gateway
It specifies the default gateway address of this device in WISP or Router mode.
Primary DNS Server
It specifies the IP address of primary DNS server of this device in WISP or Router
mode.
Secondary DNS Server
It specifies the IP address of secondary DNS server of this device in WISP or
Router mode.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
