Tenda O1 User Manual

91
Configuration procedure
Configure the CPE
Assume that the IP address of the RADIUS server is 192.168.0.200, the Key is 12345678, and the port number for
authentication is 1812.
Assume that the second SSID of the AP is used.
Step 1 Choose Wireless > Basic.
Step 2 Enable the wireless function.
Step 3 Change the value of the SSID text box to hotspot.
Step 4 Set Security Mode to WPA2.
Step 5 Set RADIUS Server, RADIUS Port, and RADIUS Password to 192.168.0.200, 1812, and 12345678
respectively.
Step 6 Set Encryption Algorithm to AES.
Step 7 Click Save.
RADIUS Server IP: 192.168.2.200
Switch
Router
Internet
Computer
CPE IP Address: 192.168.2.1

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
