Read Operators Manual For SafetyPARTS MANUAL
Copyright © 2007 Terramite Corporation
3
56
7
21
View from Operator Position of Rear Valve (Straight Boom - Non 180 Only)
4
8
9
ITEM PART NUMBER DESCRIPTION QTY.
1 13431 Handle, Outrigger, T5C/T5D/T6/T7/T9 2
2 13410 Bracket, Aluminum, Rear Valve Handle 2
3 16410 Wobblestick Eye Bolt 2
4 13429 Valve, Main Relief 1
5 13418 Pin, Pivot, Valve Hose Link, T5C/T5D/T7 8
6 13423 Valve, Boot Spool Protector 4
7 13401 Kit, Load Check 9
8 13456 Relief, Port 2600# 1
9 13454 Relief, Port 2000# 2
2.35
