WWW.TERRAMITE.COM
Charleston, WV/USA
USA 1.800.428.3772
Intl. 1 .304.776.4231
Read Operators Manual For Safety PARTS MANUAL
Copyright © 2007 Terramite Corporation
ITEM PART NUMBER DESCRIPTION QTY.
1 13073 Handle, Wobblestick, Left Rear, T5C/T5D/T6/T7/T9 1
2 13431 Handle, Outrigger, T5C/T5D/T6/T7/T9 2
3 13123 Handle, Wobblestick, Right Rear, T5C/T5D/T6/T7/T9 1
4 13942 Knob, Red Wobblestick Handle, Valve, T5C/T5D/T6/T7/T9 2
5 15102 Cover, Rear Valve (Boom Latch), T5C/T7/T9 1
6 13135 Cable, Boom Latch Control, T-Handle, T7/T9 1
7 22222 Spring For Boom Latch 1
8 22023 Washers For Latch 1
View of Operator Position at Rear Valve (Prior to 1-1-01 Non 180 Only)
1 2 3
4
6
5
2.36
