TESTO 300 - Pa Measurement

14 Performing the measurement
81
14.2.17 4 Pa measurement
The 4 Pa measurement is only available with instruments that have the
dilution option available.
1
Call up function: | 4 Pa measurement
2
Set parameters or enter values.
All values that can be modified have a dotted underlining.
3
Connect adapter 0554 1203, hose connection kit and capillary hoses
0554 1215 as shown in the illustration.
4
Tap Next.

Hose test is started.
5
Tap Next.

Measurement starts.

Readings and measuring time are displayed.
Follow the notes in the display.

The readings are automatically saved and displayed after the
measurement has been completed.
6
End measurement early: tap .
Guidelines for the qualification test for differential pressure measuring
instruments for the measurement of underpressures in rooms where firing
installations are set up
These guidelines were created by the ZIV (Guild of Master Chimney Sweeps) in
collaboration with differential pressure measuring instrument manufacturers, the
TÜV SÜD Industrie Service GmbH test centre, firing and heat technology, and
the DVGW (German Technical and Scientific Association for Gas and Water).
Areas of application and purpose:
Firing installations which are dependent on indoor air must not be set up in
rooms with air extraction equipment. However, insofar as no dangerous
underpressure can arise while the firing installations are in operation,
