6 Using the product
60
6.2.3. Draft-Measurement
Calling up the function:
✓ A flue gas probe must be connected.
Performing the measurement:
The pressure socket of the instrument must be free (i.e.
unpressurized, not closed).
Do not measure for longer than 5 min, as the drift of the
pressure sensor means that the meas. views could be
outside the tolerance limits.
- Draft zeroing.
2. Position the flue gas probe in the hot spot (area of the highest
flue gas temperature).
The display showing the maximum measured flue gas
temperature (FT max) helps when positioning the probe.
- The reading is displayed.
Options:
> [Options] → Clipboard: Data are saved to the clipboard:
> [Options] → Delete clipboard: Any data saved to the clipboard
is deleted.
> [Options] → Save: The meas. views are saved in a protocol.
> [Options] → Show Graphic: The meas. views are displayed in
form of a line graph.
> [Options] → Measurement View: (This function is not
available during a measurement): The measurement view menu
is opened.
4.
