6.3.2.1 Displays
Quality of the radio link.
Indicator as to whether a communication with the Saveris base or a
Saveris router or Saveris converter is being carried out.
Status of batteries.
Unit of the reading:
- % for humidity measurement
- mA for current measurement
- °Ctd or °Ftd for dewpoint measurement.
Reading.
Indication as to whether the reading has overshot the upper ( ) limit
value or undershot the lower ( ) limit value.
Number of the channel.
Display for a second sensor in the probe.
6.3.3 testo Saveris radio data logger LED status
displays
Registering on the Saveris base
-
Hold down the connect key on the rear of the data logger until the LED
begins to flash orange.
Display Explanation
Flashing orange
Attempt to establish the connection to the Saveris base.
Lit up green
Registration on the Saveris base was successful.
Lit up red
Registration on the Saveris base failed.
