6 Product description
26
Symbol Description
Alarm message
Measurement channel 1
Measurement channel 2
Alarm status: upper limit value overshot
Alarm status: lower limit value undershot
6.5 Ethernet data logger for testo Saveris
Display for showing readings and transmission information.
LED for status display.
Connect key.
Catch for the wall bracket.
Guide rails for the wall bracket.
Input for external probes.
Input for external 24 V AC/DC power supply, M1.6 x 1.5 cable coupling.
Input for Ethernet interface
Input for service interface
