Chapter 11
SWRU191C–April 2009– Revised January 2012
Sleep Timer
The Sleep Timer is used to set the period during which the system enters and exits low-power modes
PM1 and PM2. The Sleep Timer is also used to maintain timing in Timer 2 when entering power mode
PM1 or PM2.
The main features of the Sleep Timer are the following:
• 24-bit timer up-counter operating at 32-kHz clock rate
• 24-bit compare with interrupt and DMA trigger
• 24-bit capture
Topic ........................................................................................................................... Page
11.1 General ........................................................................................................... 134
11.2 Timer Compare ................................................................................................ 134
11.3 Timer Capture ................................................................................................. 134
11.4 Sleep Timer Registers ...................................................................................... 135
