www.ti.com

Timer 2 Registers

T2EVTCFG (0x9C) – Timer 2 Event Configuration (CC2541)

Bit Name Reset R/W Function

No.

7:4

TIMER2_EVENT2_CFG

0 R/W Selects the event that triggers a T2_EVENT2 pulse

0000: t2_per_event

0001: t2_cmp1_event

0010: t2_cmp2_event

0011: t2ovf_per_event

0100: t2ovf_cmp1_event

0101: t2ovf_cmp2_event

0110: Reserved

0111: No event

1000: t2ovf_long_cmp1_event

1001: t2ovf_long_cmp2_event

1010–1110: Reserved

1111: No event

3:0

TIMER2_EVENT1_CFG

0 R/W Selects the event that triggers a T2_EVENT1 pulse

0000: t2_per_event

0001: t2_cmp1_event

0010: t2_cmp2_event

0011: t2ovf_per_event

0100: t2ovf_cmp1_event

0101: t2ovf_cmp2_event

0110: Reserved

0111: No event

1000: t2ovf_long_cmp1_event

1001: t2ovf_long_cmp2_event

1010–1110: Reserved

1111: No event

217

SWRU191C–April 2009–Revised January 2012 Timer 2 (MAC Timer)
