USB Registers

www.ti.com

USBF5 (0x622A) – Endpoint-5 FIFO

Bit Name Reset R/W Description

7:0

USBF5[7:0]

0x00 R/W Endpoint 5 FIFO register. Reading this register unloads one byte from the EP5 OUT

FIFO. Writing to this register loads one byte into the EP5 IN FIFO.

206

USB Controller SWRU191C– April 2009– Revised January 2012

Submit Documentation Feedback

Default Chapter2
