Appendix C

SWRU191C–April 2009– Revised January 2012

References

References and other useful material:

1. IEEE Std. 802.15.4-2006: Wireless Medium Access Control (MAC) and Physical Layer (PHY)

specifications for Low Rate Wireless Personal Area Networks (LR-WPANs)

http://standards.ieee.org/getieee802/download/802.15.4-2006.pdf

2. CC2530 Data Sheet (SWRS081)

3. CC2531 Data Sheet (SWRS086)

4. CC2533 Data Sheet (SWRS087)

5. CC2540 Data Sheet (SWRS084)

6. CC2541 Data Sheet (SWRS110)

7. Bluetooth® Core Technical Specification document, version 4.0

https://www.bluetooth.org/technical/specifications/adopted.htm

8. Universal Serial Bus Revision 2.0 specification http://www.usb.org/developers/docs/usb_20_101111.zip

367

SWRU191C–April 2009–Revised January 2012 References

Submit Documentation Feedback
