Table 5-1. Bill of Materials (continued)
Designator Quantity Value Description
Package
Reference
Part Number Manufacturer
Alternate Part
Number
Alternate
Manufacturer
R37, R40, R68,
R69, R70, R71
6 10.0k RES, 10.0 k, 1%, 0.05 W, 0201 0201 CRCW020110K0FKED Vishay-Dale
R43, R48 2 499k RES, 499 k, 1%, 0.063 W, AEC-
Q200 Grade 0, 0402
0402 CRCW0402499KFKED Vishay-Dale
R44, R50 2 59.0k RES, 59.0 k, 1%, 0.063 W, AEC-
Q200 Grade 0, 0402
0402 CRCW040259K0FKED Vishay-Dale
R45, R51,
R101, R102
4 249k RES, 249 k, 1%, 0.063 W, AEC-
Q200 Grade 0, 0402
0402 CRCW0402249KFKED Vishay-Dale
R46, R52 2 976k RES, 976 k, 1%, 0.063 W, AEC-
Q200 Grade 0, 0402
0402 CRCW0402976KFKED Vishay-Dale
R47, R54 2 40.2k RES, 40.2 k, 1%, 0.063 W, AEC-
Q200 Grade 0, 0402
0402 CRCW040240K2FKED Vishay-Dale
R63, R64 2 3.83k RES, 3.83 k, 1%, 0.05 W, 0201 0201 CRCW02013K83FKED Vishay-Dale
R97 1 1.02k RES, 1.02 k, 1%, 0.05 W, 0201 0201 RC0201FR-071K02L Yageo America
R98, R99 2 100k RES, 100 k, 1%, 0.063 W, 0402 0402 CRCW0402100KFKED Vishay-Dale
R100 1 23.7k RES, 23.7 k, 1%, 0.1 W, AEC-
Q200 Grade 0, 0402
0402 ERJ-2RKF2372X Panasonic
R103, R104 2 1.00Meg RES, 1.00M, 1%, 0.063W, AEC-
Q200 Grade 0, 0402
0402 CRCW04021M00FKED Vishay-Dale
R109 1 523k RES, 523 k, 1%, 0.063 W, AEC-
Q200 Grade 0, 0402
0402 CRCW0402523KFKED Vishay-Dale
S1, S2 2 DIP Switch, SPST 4Pos, Slide,
SMT
6.2x2.0x6.2mm TDA04H0SB1 C&K Components
S3 1 SWITCH TACTILE SPST-NO
0.05A 12V
3x1.6x2.5mm B3U-1000P Omron Electronic
Components
SH-J1, SH-J2,
SH-J3, SH-J4,
SH-J5, SH-J6,
SH-J7, SH-J8,
SH-J9
9 1x2 Shunt, 100mil, Gold plated, Black Shunt SNT-100-BK-G Samtec 969102-0000-DA 3M
TP2, TP3, TP4,
TP5, TP8, TP9,
TP10, TP11,
TP13, TP14,
TP15, TP16,
TP17, TP19,
TP20, TP22
16 Test Point, Miniature, SMT Testpoint_Keystone
_Miniature
5015 Keystone
