Table 5-1. Bill of Materials (continued)
Designator Quantity Value Description
Package
Reference
Part Number Manufacturer
Alternate Part
Number
Alternate
Manufacturer
U1 1 USB Type-C and USB PD
Controller with Integrated Power
Switches Optimized for Power
Applications
WQFN38 TPS25730DRJKR Texas Instruments
U2, U3 2 22V Precision Surge Protection
Clamp, DRV0006A (WSON-6)
DRV0006A TVS2200DRVR Texas Instruments Texas Instruments
U4 1 USB Type-C and USB PD
Controller with Integrated Power
Switches Optimized for Power
Applications
WQFN38 TPS25751DREFR Texas Instruments
U5 1 USB Type C Short-to-VBus and
IEC ESD Protector for CC,
YFF0009AJAJ (DSBGA-9)
YFF0009AJAJ TPD2S300YFFR Texas Instruments Texas Instruments
U6 1 EEPROM Memory IC 512Kb (64K
x 8) I²C 1MHz 900ns 8-SOIC
SOIC8 CAT24C512WI-GT3 ON Semi
U7 1 ESD Protection Array for High-
Speed Data Interfaces, 2
Channels, -40 to +85 degC, 3-pin
SOT (DRT), Green (RoHS & no
Sb/Br)
DRT0003A TPD2E009DRTR Texas Instruments
U8 1 Tiva C Series Microcontroller, 256
KB Flash, 32 KB SRAM, 12 Bit,
12 Channels, -40 to 105 degC,
64-Pin LQFP (PM), Green (RoHS
& no Sb/Br), Tape and Reel
PM0064A TM4C123GH6PMTR Texas Instruments
U9, U11 2 500mA, Low IQ, Small Size, Low
Dropout Regulator, DQN0004A
(X2SON-4)
DQN0004A TLV75533PDQNT Texas Instruments TLV75533PDQN
R
Texas Instruments
U10 1 3.5V to 60V 5A Synchronous
Step-Down Voltage Regulator,
RNP0030A (WQFN-30)
RNP0030A LM76005RNPR Texas Instruments Texas Instruments
U15 1 5V Precision Surge Protection
Clamp, DRV0006A (WSON-6)
DRV0006A TVS0500DRVR Texas Instruments Texas Instruments
Y1 1 Crystal, 16MHz, 8pF, SMD 3.2x0.75x2.5mm NX3225GA-16.000M-STD-
CRG-1
NDK
FID1, FID2,
FID3
0 Fiducial mark. There is nothing to
buy or mount.
N/A N/A N/A
R32, R33,
R110, R111
0 0 RES, 0, 5%, 0.063 W, AEC-Q200
Grade 0, 0402
0402 CRCW04020000Z0ED Vishay-Dale
www.ti.com Hardware Design Files
SLVUCP9A – NOVEMBER 2023 – REVISED MARCH 2024
Submit Document Feedback
TPS25751 Evaluation Module 47
Copyright © 2024 Texas Instruments Incorporated
