Page 1020
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
FIG/ITEM PART NUMBER NOMENCLATURE
1234567
EFFECT
UNITS
PER
ASSY
1- MBCS14550 ICD MISSION SEAT ETSO RF
5 MBCS8753 . Guide, harness 2
10 MBCS8859 . 5-point harness 1
15 A114-6-D . Bolt, mush HD 10-32 UNF 1.10 in. 2
20 SP125D . Washer 2
25 P32333 . Nut, self-lock H42-3 10-32 UNF 2
30 SP93D20 . Grommet BU 0.15, 0.6251 in. I/D 1
35 MBCS14561 . Support, lumbar mission (thin) 1
40 MBCS7180 . Headrest and cover 1
45 MBCS8752 . Spring, adjust, headrest 2
-50 MBCS14557 . Cushion back assembly 1
55 - . . Cushion back - front NP
60 - . . Cushion back - rear NP
65 MBC14554 . Sitting cushion assembly 1
70 MBCS14566 . Label, warning positioning 2
75 MBCS14565 . Label, identification, seat 1
80 MBCS13845-1 . Label, seat manufacture 1
85 MBCS14551 . G.A. mission seat ETSO RF
90 MBCS8903 . . Guard 1
95 AGS2050-519BH . . . Rivet, pop 0.156 in. 2
100 A114-10-E . . Bolt, mush HD 1/4-28 UNF 2
105 MBCS8905 . . Spacer 2
110 P32334 . . Nut, self-lock H42-4 1/4-28 UNF 2
115 A114-10-E . . Bolt, mush HD 1/4-28 UNF 2
120 P32334 . . Nut, self-lock H42-4 1/4-28 UNF 2
125 A114-1/2B . . Bolt, mush HD 6-32 Cres 2
130 MBCS8904 . . Spacer 2
135 P32331 . . Nut, self-lock H42 L06 6-32 UNC 2
- item not illustrated
ICA-680A-25-80003A
Sep 4/2020
