Page 1021
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
140 MBCS123
19 . . Cover assembly 1
145 MBCS8787 . . Cover, rear base 1
150 P38216 . . . Fastener, touch and close (37 inch) 1
155 A114-1/2D . . Bolt, mush HD 10-32 UNF 0.55 in. 4
160 P32333 . . Nut, self-lock H42-3 10-32 UNF 4
165 MBCS7208 . . Label, restraint status 1
170 MBCS14567 . . Carriage floor ETSO 1
175 MBCS8718 . . Carriage floor plunger 1
180 MBCS14568 . . Spigot retaining ETSO 4
185 P32331 . . Nut self-lock H42-4 1/2-28 UNF 4
190 MBCS8682 . . Lever, lock operating 2
195 MBCS6959 . . Plunger, locking floor 2
200 P37602 . . Spring, compression 2
205 P33035 . . Pin, dowel 3/32 dia x 0.5 in. 2
210 SP4Z-B16 . . Pin, clevis 3/16 dia x 1.00 in. 2
215 SP90C4 . . Pin, split 1/16 dia x 0.50 in. 2
220 MBCS8953 . . Foot LH (rear LH and front RH) 2
225 MBEU56269 . . Washer, rubber 4
230 SP4Z-B24 . . Pin, clevis 3/16 dia x 1.8 in. 2
235 SP90C4 . . Pin, split 1/16 dia x 0.50 in. 2
240 MBCS8790 . . Plunger, secure floor 2
245 P37843 . . Spring, compression 2
250 MBCS8999 . . Pin, locking track (rear LH and front RH) 2
255 MBCS8735 . . Top floor fitting (rear RH and front LH) 2
260 MBCS8957 . . Pin, rear claw 2
265 SP90C4 . . Pin, split 1/16 dia x 0.37 in. 2
270 MBCS8960 . . Packer, lower side frames 2
275 SP4Z-A10 . . Pin, clevis 5/32 dia x 0.70 in. 2
280 SP90C3 . . Pin, split 1/16 dia x 0.37 in. 2
- item not illustrated
FIG/ITEM PART NUMBER NOMENCLATURE
1234567
EFFECT
UNITS
PER
ASSY
To Next Page
