Page 1022
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
285 MBCS8954 . . Foot, RH (front LH and rear RH) 2
290 MBEU56269 . . Washer, rubber 4
295 SP4Z-B24 . . Pin, clevis 3/16 dia x 1.8 in. 2
300 SP90C4 . . Pin, split 1/16 dia x 0.50 in. 2
305 MBCS8790 . . Plunger, secure floor 2
310 P37843 . . Spring, compression 2
315 MBCS8998 . . Pin, locking track (rear RH and front LH) 2
320 MBCS8736 . . Top floor fitting (front RH and rear LH) 2
325 MBCS8957 . . Pin, rear claw 2
330 SP90C4 . . Pin, split 2
335 MBCS8960 . . Packer, lower side frames 2
340 SP4Z-A10 . . Pin, clevis 5/32 dia x 0.70 in. 2
345 SP90C3 . . Pin, split 1/16 dia x 0.37 in. 2
350 MBCS14560 . . Backrest assembly 1
355 MBCS12722 . . Lever assembly, fore/aft 1
360 MBCS12276 . . Spacer, lever bracket 1
365 SP4Z-A16 . . Pin, clevis 5/32 dia x 1.00 in. 1
370 SP90C3 . . Pin, split dia x 0.37 in 1
375 MBCS12723 . . Lever assembly, recline 1
380 MBCS12721 . . Lever assembly, raise/lower 1
385 MBCS12277 . . Spacer, lever bracket 1
390 SP4Z-A16 . . Pin, clevis 5/32 dia x 1.00 in. 1
395 SP90C3 . . Pin, split 1/16 dia x 0.37 in 1
400 P38078 . . Cover plug, polythene 3
405 MBCS8840 . . Bracket, levers 2
410 P32332 . . Nut, self-lock H42L08 8-32 UNC 4
415 A104-1/2 C . . Bolt, Hex HD 8-32 UNC 4
420 MBCS12272 . . Cable assembly, fore/aft 1
425 P32334 . . . Nut, self-lock H42-4 1/4-28 UNF 1
- item not illustrated
FIG/ITEM PART NUMBER NOMENCLATURE
1234567
EFFECT
UNITS
PER
ASSY
