Page 1023
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
430 MBCS122
71 . . Cable assembly, recline 1
435 MBCS12274 . . Cable assembly, vertical 1
440 P32334 . . . Nut, self-lock H42-4 1/4-28 UNF (part of recline
& vertical cable assemblies)
2
445 P32333 . . Nut, self-lock H42-3 10-32 UNF 2
450 MBCS7184 . . Pin, gas strut anchor 2
455 P32335 . . Nut, self-lock H42-5 5/16-24 UNF 2
460 SP93D20 . . Grommet 1
465 MBCS8845 . . Claw assembly 4
470 P32334 . . Nut, self-lock H42-4 1/4-28 UNF 8
475 MBCS6949 . . Bearing, thrust 8
480 A114-1/2B . . Bolt, mush HD 6-32 Cres 8
485 P32331 . . Nut, self lock H42 L06 6-32 UNC 8
490 P37385 . . Spring, compression 1
495 MBCS6423 . . Pin, lock housing 1
500 MBCS13920 . . Plunger, locking 1
505 MBCS8828 . . Plunger, vertical lock 2
510 P37372 . . Spring, compression 2
515 MBCS7257 . . Housing, vertical lock 2
520 SP90C4 . . Pin, split 1/16 dia x 0.50 in. 2
525 MBCS8756 . . Gas strut 2
530 MBCS8825 . . Lever, lock fore/aft 1
535 SP4Z-B10 . . Pin, clevis 3/16 dia 0.70 in. 1
540 SP90C4 . . Pin, split 1/16 dia x 0.50 in. 1
545 MBCS7118 . . Crossbeam 1
550 A104-15E . . Bolt, hex HD 1/4-28 UNF x 2.10 in. 2
555 MBCS6952 . . Spacer, locking 2
560 P32334 . . Nut self lock H42-4 1/4-28 UNF 2
565 MBCS7121 . . Beam middle 1
- item not illustrated
FIG/ITEM PART NUMBER NOMENCLATURE
1234567
EFFECT
UNITS
PER
ASSY
ICA-680A-25-80003A
Sep 4/2020
