Page 1024
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
570 A114-1/2B . . Bolt, mush HD 6-32 Cres 4
575 P32331 . . Nut self lock H42 L06 6-32 UNC 4
580 MBCS8834 . . Armrest 2
585 MBCS8836 . . Screw, armrest 2
590 A114-7C . . Bolt, mush HD 8-32 UNC 2
595 P31006 . . Nut, nylon cap 2
600 MBEU61540-1 . . O-ring, No 121 DTD5607 4
605 MBCS8928 . . Cover, LH armrest 1
610 P32332 . . . Nut, self-lock H42L08 8-32 UNF 3
615 MBCS8923 . . Cover, RH armrest 1
620 P32332 . . . Nut, self-lock H42L08 8-32 UNF 3
625 MBCS7170 . . Spigot, armrest 2
630 MBCS7171 . . Plunger, detent, armrest 2
635 P38079 . . Spring, compression LC-042C-8SS 2
640 MBCS7169 . . Tube, baulking 2
645 P38281 . . Lever, rotate 1
650 A114-14D . . Bolt, mush HD 10-32 UNF 1.90 in. 2
655 MBCS7209 . . Spacer 2
660 P32333 . . Nut, self-lock H42-3 10-32 UNF 2
665 MBCS12273 . . Cable assembly, rotation 1
670 MBCS7158 . . Rack 2
675 MBCS8907 . . Pin, pivot 2
680 SP90C4 . . Pin, split 1/16 dia x 0.50 in. 2
685 MBCS8838 . . Gas strut 2
690 MBCS8839 . . Spacer 2
695 SP4Z-A16 . . Pin, clevis 5/32 dia x 1.00 in. 2
700 SP90C3 . . Pin, split 1/16 dia x 0.37 in. 2
705 SP4Z-A11 . . Pin, clevis 5/32 dia x 0.75 in. 2
710 SP90C3 . . Pin, split 1/16 dia x 0.37 in. 2
- item not illustrated
FIG/ITEM PART NUMBER NOMENCLATURE
1234567
EFFECT
UNITS
PER
ASSY
