Textron Aviation 680A - Page 135

Page 1026
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
860 P32334 . . Nut, self-lock H42-4 1/4-28 UNF 2
865 A114-10E . . Bolt, mush HD 1/4-28 UNF 2
870 P32334 . . Nut, self-lock H42-4 1/4-28 UNF 2
875 MBCS6103 . . Spool, -ve G-reel 2
880 A114-4E . . Bolt, mush HD 1/4-28 UNF x 1.00 in. 2
885 P32334 . . Nut, self-lock H42-4 1/4-28 UNF 2
- item not illustrated
FIG/ITEM PART NUMBER NOMENCLATURE
1234567
EFFECT
UNITS
PER
ASSY
ICA-680A-25-80003A
Sep 4/2020
