3.3.3 Manual Mode Button
Pressing the MANUAL MODE button activates the capability to jog and reposition the machine.
!
CAUTION
Pressing the MANUAL MODE button again will turn off the manual mode
and will ask if you want to return the machine to the last known parked
position.
3.3.4 Zero Button
Resets the X & Y counters to ZERO after locating a new starting point on the table using the jog function keys.
HINT: Pressing the zero button will automatically turn off the manual mode button, if it was activated on.
3.3.5 Start Button
Sends the cutting program from the “next job preview” screen to the “current job” screen to be executed, and starts the cutting cycle
sequence. The START- button illuminates and is on during the entire execution of the program. No programs can be transferred to the
current job screen if the START button is on.
HINT: If this button is pressed during a programmed delay, the delay is terminated at once without memorizing the interrupted time
of the delay in cutting parameters.
3.3.6 Torch ON/OFF Button
Pressing the TORCH ON / OFF button when manual mode is activated, will either manually start or turn off the cutting process.
!
CAUTION
When the start button is activated, and the cutting sequence is initiated, the TORCH ON/OFF
button will automatically illuminate indicating the torch is on and the cutting sequence has
started. When the program ends, the light will go out automatically indicating end of cut. If
TORCH ON/OFF is pressed and released during the cutting process, machine motion and cut-
ting stops. Pressing this button again starts machine motion and the cutting sequence with
any programmed delays
.
HINT: You can’t use TORCH ON/OFF for manual cutting, eg. scrap lines. Manual button on push the TORCH ON and the pierce sequence
will begin. Immediately after pushing TORCH you can start pushing a directional button, the machine won’t start to move before the
pierce sequence has ended.
