Thermal Dynamics SIGNATURE PAK 1250XRTM - Section 1: System Description; 1.1 General Description

1
1.1 GENERAL DESCRIPTION
GENERAL INFORMATION
The complete Signature PAK 1250 XR System includes:
• Signature PAK 1250 XR Power Supply
• PCH-52 Hand Torch (or) PCM-52 Machine Torch
• 25 ft (7.6 m) or 50 ft (15.2 m) Torch Leads
• PCH/M-52 Spare Parts Kit
• 25 ft (7.6 m) Work Cable and Clamp
• Running Gear and Handle
• Air Line Filter and Regulator Assembly
(or) High Pressure Gas Regulators
Figure 1-A The Signature PAK 1250 XR Plasma Arc Cutting/Gouging System
R
R
Signature PAK 1250 XR
Power Supply
PCH/M-52
Torch with Leads
Work Cable
and Clamp
Spare Parts Kit
A-01451
SECTION 1: SYSTEM DESCRIPTION
