PARTS LIST
38
5.1 SYSTEM COMPONENTS & ACCESSORIES
Fig. Item Qty. Catalog Description
No. Number
5-1 1 1 3-6570A PAK 1250 XR Power Supply with Running Gear and Work Cable
5-1 2 1 2-2936 PCH-52 70° Hand Torch with 25 ft (7.6 m) Leads
5-1 1 2-2937 PCH-52 70° Hand Torch with 50 ft (15.2 m) Leads
5-1 1 2-2330 PCH-52 90° Hand Torch with 25 ft (7.6 m) Leads
5-1 1 2-2331 PCH-52 90° Hand Torch with 50 ft (15.2 m) Leads
5-1 1 2-2938 PCM-52 180° Machine Torch with 25 ft (7.6 m) Leads
(Includes Pinion Assembly)
5-1 1 2-2939 PCM-52 180° Machine Torch with 50 ft (15.2 m) Leads
(Includes Pinion Assembly)
5-1 3 1 8-1124 Work Cable with Clamp - 25 ft (7.6 m)
5-1 1 9-5865 Right Side Panel- with Overlay (Not Shown)
5-1 1 8-6184 Upper Side Panel Overlay - Right Side (Not Shown)
5-1 4 1 9-5868 Left Side Panel- with Overlay
5-1 5 1 8-6186 Upper Side Panel Overlay - Left Side
5-1 6 2 8-6185 Lower Side Panel Overlay
5-1 13 1 9-5863 Front Panel
5-1 14 1 9-5864 Front Panel Overlay
5-1 7 1 8-6188 Handle
5-1 8 1 9-4282 Axle
5-1 9 2 9-4283 Wheel
5-1 10 2 9-5539 Retaining Ring
5-1 11 4 Flat Washer- 1/2 in (13 mm) I.D.
5-1 12 2 7-3128 Front Caster
5-1 1 7-3117 Cylinder Rack Running Gear
5-1 1 7-3139 Air Line Filter Assembly - Includes All Fittings
5-1 2 9-1020 Air Line Filter Assembly - Filter Only
5-1 1 9-1021 Replacement Filter Element - First Stage
5-1 1 9-1022 Replacement Filter Element - Second Stage
5-1 2 9-5524 Air Line Regulator Assembly
5-1 1 8-2150 Air Line Regulator Mounting Bracket
5-1 1 8-5527 Plasma Gas Hose - 1.5 ft (457 mm)
5-1 1 8-5528 Secondary Gas Hose - 1.5 ft (457 mm)
5-1 1 9-2184 Street Elbow Fitting (Gas Hose to Regulator)
5-1 1 9-5656 Y-Hose Assembly
5-1 1 7-3144 Male Hose Fitting (Y-Hose Assembly)
5-1 1 9-2034 Female Tee Fitting (Y-Hose Assembly)
5-1 2 8-0263 90° Adaptor Fitting (Y-Hose Assembly)
5-1 2 8-1155 Gas Hose - 12 in (305 mm) (Y-Hose Assembly)
5-1 1 9-3022 High Pressure Regulator - Air
5-1 1 9-3053 High Pressure Regulator - Argon/Hydrogen
5-1 1 9-2722 High Pressure Regulator - Nitrogen
5-1 1 9-2759 High Pressure Regulator - Carbon Dioxide
5-1 1 9-2146 Plasma Gas Hose - 10 ft (3.1 m)
5-1 1 9-2147 Secondary Gas Hose - 10 ft (3.1 m)
5-1 1 5-2935 Service Parts Kit - For 60 Hz System
5-1 1 5-2936 Service Parts Kit - For 50 Hz System
5-1 1 9-5692 Computer Control Cable Kit - 25 ft (7.6 m)
5-1 1 9-5693 Computer Control Cable Kit - 50 ft (15.2 m)
5-1 1 7-3121 SC2/XR Standoff Control
To Next Page
