2
1.2 POWER SUPPLY SPECIFICATIONS
The PAK 1250 XR is available in the following volt-amp
combinations:
Power Input
Figure 1-B Power Supply Dimensions
GENERAL INFORMATION
* 200V at 50 Hz, 220V at 60 Hz
Table 2-A (page 13) contains information on power input,
current ratings, circuit protection, and wire sizes.
Range I- 35 amps
Range II- 70 amps
Range III- 105 amps
Duty Cycle - 80%
Approximate Shipping Weight - 275 lbs. (125 kg)
Voltage Frequency Phase Amperage
200/220 60 Hz 3 74/68
200/220 50 Hz 3 74/68
200/220 50/60 Hz * 3 74/68
380/415 50 Hz 3 40/37
460 60 Hz 3 33
380/500 50 Hz 3 40/30
575 60 Hz 3 26
Output
Weight
R
22.5 in
(0.57 m)
27.0 in
(0.69 m)
18.0 in
(0.46 m)
A-01452
