PARTS LIST
44
5-5 1 1 9-4338 Ceramic Disc Capacitor Assembly - .002 mfd C10
5-5 2 1 9-5589 Spark Gap Assembly
5-5 3 2 Set Screw - #6-32UNC X 1/8" lg
5-5 4 2 9-3841 Electrode - HF Spark Gap
5-5 5 2 9-4107 Resistor - 2500 ohm, 50 w R7
5-5 6 1 9-5161 Resistor - 100 ohm, 50 w R8
5-5 7 1 9-5614 Capacitor - 240 mfd, 450 VDC C9
5-5 8 4 9-5333 PC Board Support
5-5 9 1 9-5528 High Frequency Transformer T5
5-5 10 1 9-4330 Auxiliary Transformer (For 60 Hz only) T4
5-5 (10) 1 9-4331 Auxiliary Transformer (For 50 Hz and 50/60 Hz) (T4)
5-5 1 8-4235 Auxiliary Transformer Socket
5-5 1 9-5171 Auxiliary Transformer Receptacle
5-5 11 1 8-0367 Fuse - 5 amp, 250V (For 200/220V units) 1FU
5-5 (11) 1 8-1153 Fuse - 3 amp, 500V (For 380/415 and 460V units) (1FU)
5-5 (11) 1 8-1128 Fuse - 3 amp, 600V (For 500 and 575V units) (1FU)
5-5 12 1 9-5562 Fuse Block
5-5 13 2 9-3293 14-pin Receptacle - Reverse Sex
5-5 14 2 9-3297 14-pin Socket
5-5 15 4 9-5544 Grommet
5-5 16 1 8-2156 Upper Equipment Chassis
5-5 17 1 9-5616 Capacitor Holder
5-5 18 1 9-4189 Control Logic PC Board PC1
Fig. Item Qty. Catalog Description Reference
No. Number Designator
5.5 UPPER EQUIPMENT PANEL COMPONENTS
