Thermal Dynamics SIGNATURE PAK 1250XRTM User Manual

PARTS LIST
42
5-4 1 1 8-3241 Base
5-4 2 3 Main Transformers: T1,T2,T3
9-5672 200/220V, 3-phase, 60 Hz
9-5674 200/220V, 3-phase, 50 Hz
9-5676 200/220V, 3-phase, 50/60 Hz
9-5680 380/415V, 3-phase, 50 Hz
9-5682 460V, 3-phase, 60 Hz
9-5684 380/500V, 3-phase, 50 Hz
9-5686 575V, 3-phase, 60 Hz
5-4 3 1 9-2391 Strain Relief - Input Power Cable
5-4 4 3 9-5586 Main Contactor - 24 VAC W1, W2, W3
5-4 5 1 8-1127 Fan Motor Mounting Bracket
5-4 6 1 8-1125 Fan Motor M
5-4 7 1 9-5209 Fan Motor Receptacle
5-4 8 1 8-1126 Fan Blade
5-4 9 1 9-4363 Input Voltage Terminal Board
5-4 10 1 9-4364 Contactor Wire Harness
Fig. Item Qty. Catalog Description Reference
No. Number Designator
5.4 BASE COMPONENTS
