PARTS LIST
37
ABOUT THE PARTS LIST
Figure 5-1 System and Accessories
Figure 5-2 Front Panel Components
Figure 5-3 Rear Panel Components
Figure 5-4 Base Components
Figure 5-5 Upper Equipment Panel Components
Figure 5-6 Bulkhead Components
Figure 5-7 Torch Components
Figure 5-8 Torch Accessories
An item number in parentheses indicates a component
that may differ depending on options such as the voltage
or phase configuration of a particular unit. The descrip-
tion of the item provides identification of the correct
choice for each system configuration.
Parts listed without item numbers are not illustrated, but
may be ordered by the catalog number shown. Order
replacement parts by catalog number and complete de-
scription of the part or assembly, as listed in the descrip-
tion column of the Parts List. Also include the model and
serial number of the machine as shown on the plate
attached to the front panel of the unit. Address all inquir-
ies to your authorized distributor.
If a product must be returned for service, contact your
distributor. Materials returned without proper
authorization will not be accepted.
Ordering Information
Returns
Parts List Contents
SECTION 5: PARTS LISTS
