PARTS LIST

5.8 TORCH ACCESSORIES

Fig. Item Qty. Catalog Description

No. Number

5-8 1 1 9-5644 Handle

5-8 2 1 9-5522 Switch Assembly

5-8 3 1 8-4216 Switch Retaining Sheath

5-8 4 1 8-4018 Retaining Nut

5-8 5 1 9-1901 Adaptor

5-8 6 1 8-5005 Positioning Tube

5-8 7 1 7-2827 Pinion Assembly

5-8 8 1 8-4204 Bushing (End Cap)

5-8 9 1 7-3124 Circle Cutting Attachment

5-8 1 4-5034 PCH-52 Replacement Hand Torch Leads - 25 ft (7.6 m)

5-8 1 4-5035 PCH-52 Replacement Hand Torch Leads - 50 ft (15.2 m)

5-8 1 4-5036 PCM-52 Replacement Machine Torch Leads - 25 ft (7.6 m)

5-8 1 4-5037 PCM-52 Replacement Machine Torch Leads - 50 ft (15.2 m)

5-8 1 4-2848 PCH-52 Hand Torch Leads Extension Kit - 25 ft (7.6 m)

5-8 1 4-2849 PCH-52 Hand Torch Leads Extension Kit - 50 ft (15.2 m)

5-8 1 4-2850 PCM-52 Machine Torch Leads Extension Kit - 25 ft (7.6 m)

5-8 1 4-2851 PCM-52 Machine Torch Leads Extension Kit - 50 ft (15.2 m)

5-8 1 8-1498 Torch Leads Sleeving - 25 ft (7.6 m)

5-8 1 9-3035 Torch Leads Sleeving - 50 ft (15.2 m)

5-8 1 9-5662 Negative Torch Lead - 25 ft (7.6 m)

5-8 1 9-5663 Negative Torch Lead - 50 ft (15.2 m)

5-8 1 9-5664 Plasma Gas Hose - 25 ft (7.6 m)

5-8 1 9-5665 Plasma Gas Hose - 50 ft (15.2 m)

5-8 1 9-4279 Positive Pilot Wire - 25 ft (7.6 m)

5-8 1 9-4280 Positive Pilot Wire - 50 ft (15.2 m)

5-8 1 9-4276 Control Cable Assembly - 25 ft (7.6 m)

5-8 1 9-4277 Control Cable Assembly - 50 ft (15.2 m)

5-8 1 9-3294 14-pin Plug- for Control Cable (Console End)

5-8 1 9-3295 Cable Clamp - for Control Cable Plug

5-8 1 9-5170 Pin - for Control Cable Plug

5-8 2 8-5085 Ferrule - Negative Lead

5-8 1 8-7033 Fitting - Negative Lead, Console End

5-8 1 8-4190 Fitting - Negative Lead, Torch End

5-8 2 8-5013 Ferrule - Plasma Gas Hose

5-8 1 8-5518 Nut - Plasma Gas Hose, Console End

5-8 1 8-0328 Fitting - Plasma Gas Hose, Console End

5-8 1 8-0338 Fitting - Plasma Gas Hose, Torch End

5-8 1 8-0339 Nut - Plasma Gas Hose, Torch End

5-8 10 1 7-3114 Remote Pendant Control Assembly

5-8 11 1 9-4229 Switch - for Remote Pendant

5-8 12 1 9-4228 Cord Grip - for Remote Pendant

5-8 13 1 8-1662 Handle Only - for Remote Pendant

5-8 14 1 9-3294 14-pin Plug - for Remote Pendant

5-8 15 3 9-3296 Pin - for Remote Pendant Plug

5-8 16 1 9-3295 Cable Clamp - for Remote Pendant
