Functional Description
Mass Spectrometer
Thermo Scientific TSQ Quantum XLS Series User Guide 21
Figure 9. Transfer line
Mass Spectrometer
The TSQ Quantum XLS Series mass spectrometers provides sample ionization and mass
analysis of samples introduced from a gas chromatograph or direct insertion probe. The mass
spectrometer uses a triple-quadrupole mass analyzer with an ion source external to the mass
analyzer. Several important features of the TSQ Quantum XLS Series mass spectrometers are
as follows:
• High sensitivity and resolution
• m/z 10 to 3000 mass range for the TSQ Quantum XLS, and m/z 10 to 1500 mass range
for the TSQ Quantum XLS Ultra
• EI and CI ionization modes
• Positive and negative ion polarity modes
• MS and MS/MS scan modes
• Full-scan, SIM, SRM, iSRM, QED MS, AutoSIM, and data-dependent scan types
The mass spectrometer includes the following components:
• Controls and Indicators
• EI/CI Ion Source
• Ion Optics
Mass spectrometer
ion source end
GC end
Inlet for
calibration gas
and CI gas
