Thermo Scientific TSQ Quantum XLS User Manual

4
Tuning and Calibrating
Creating a Quality Control (QC) Tune Report
72 TSQ Quantum XLS Series User Guide Thermo Scientific
Figure 40. QC tune report
Y To create and save a QC tune report
1. Choose View > QC Report to open the TSQ QC Report dialog box.
2. Click Start to start the QC report procedure.
3. After the procedure terminates, click View Report to view the QC report as a PDF file.
4. Save the PDF file.
QQ Q p
Dec 02, 2011 15:51:56 TSQ Quantum XLS Ultra S/N: TQU01792
Device SetPoint Readback
Lens 1 (V) -45.0 -45.5
Lens 2 (V) -180.0 -180.7
Lens 3 (V) -25.0 -25.2
Lens 4 (V) -10.0 -10.0
Lens 1-1 Offset (V) -9.6 -10.0
Emission Current (uA) 50 48
Electron Lens (V) 10 10
Electron Energy (eV) -70 -69
Source Temperature (C) 100 100
Ion Gauge Pressure (Torr) 7.1e-06
Q1 Peak Width(amu): 0.7
Air/Water Leak Check: FAIL
qcr20111202155106 #1 ST: 3.02 uS: 1 NL: 2.07E7
68 70
m/z
218 220
m/z
500 502 504
m/z
0
10
20
30
40
50
60
70
80
90
100
Relative Intensity
0
10
20
30
40
50
60
70
80
90
100
Relative Intensity
0
10
20
30
40
50
60
70
80
90
100
Relative Intensity
71.213
69.030
219.021
501.865
qcr20111202155106 #11 ST: 1.02 uS: 1 NL: 2.76E7 + c CI Q1MS [46.500-700.500]
100 200 300 400 500 600
m/z
0
20
40
60
80
100
Relative Intensity
218.977
130.966
263.972
501.946
413.943
99.960
463.946
313.982
613.997375.932 551.963 673.685
Cal. Mass(m/z) Exact Mass(m/z) Intensity(cts) Ion Ratio(%)
68.971 68.995 14484893 52
218.977 218.986 27647784 100
501.946 501.971 6361739 23
Signature_____________________________ Date________________________
