Service Menu
3-82 Model 42i Low Source Instruction Manual Thermo Electron Corporation
Service Menu The Service menu appears only when the instrument is in the service mode.
To put the instrument into service mode:
• In the Main Menu, choose Instrument Controls > Service Mode.
• Press to toggle and set the service mode on.
Advanced diagnostic functions are included in the service mode.
Meaningful data should not be collected when the instrument is in the
service mode.
• In the Main Menu, choose Service.
MIN TRIG(CEILING/FLOOR):
ACTUAL TRIGGER: CEILING
SET TRIGGER TO: FLOOR ?


 TOGGLE AND SAVE VALUE
RANGE AVG DIAGS ALARM
SERVICE:
>PMT VOLTAGE ADJUSTMENT
RANGE MODE SELECT
CONVERTER SET TEMP
PRESSURE CALIBRATION
INPUT BOARD CALIBRATION
TEMPERATURE CALIBRATION
ANALOG OUT CALIBRATION
ª
RANGE AVG DIAGS ALARM
ANALOG INPUT CALIBRATION
OZONATOR SAFETY
EXTENDED RANGES
DILUTION RATIO
DISPLAY PIXEL TEST
RESTORE USER DEFAULTS
