Table Point The Table Point submenu allows the user to set up an individual table
point.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config > Select Channel > Point 1-10.
Volts The Volts screen allows the user to set the input voltage for the selected
table point in the conversion table from 0.00 to 10.50. The default table is a
two-point table with point 1: 0.00 V = 000.0 U and point 2: 10.00 V =
10.0 U.
• In the Main Menu, choose Instrument Controls > I/O Configuration >
Analog Input Config > Select Channel > Select Point > Volts.
• Use and to move the cursor up and down.
• Press to save the new value.
TABLE POINT 01 CONFIG:
>VOLTS 0.00
USER VALUE 0.00
RANGE AVG DIAGS ALARM
TABLE POINT 01 VOLTS:
CURRENTLY: 0.00
SET TO: 00.00
§¨ MOVE CURSOR
©ª CHANGE VALUE  SAVE
RANGE AVG DIAGS ALARM
