MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 24 THOMSON TECHNOLOGY
Warning
Below is a list of warnings that can be shown on the display. The warnings will be shown as an
alarm in the alarm window. The alarms can be acknowledged from the display, but they will be
visible until the alarm disappears in the ECM module.
Warning list Warning list
Coolant temp. high
ECU power supply high
Charge air temp. high
ECU power supply low
Intercooler coolant temp. high Generator temp. high
Lube oil temp. high Holding tank high level
ECU temp. high Holding tank low level
Engine speed too low Generator winding 1 high temp.
Prelube fail. Generator winding 2 high temp.
Start speed not reached Generator winding 3 high temp.
Common alarm (yellow) Ambient temp. high
Lube oil pressure low Water in fuel 1
Coolant level low Water in fuel 2
Intercooler coolant level low Fuel temp. high
ECU defect Exhaust bank A high temp.
Speed demand failure Exhaust bank B high temp.
Power supply low voltage Fuel high pressure 1
Power supply high voltage Fuel high pressure 2
Overspeed Day tank high level
Lube oil press. low
Day tank low level
Coolant temp. high
Run-up speed not reached
Lube oil temp. high
Idle speed not reached
Charge air temp. high
Shutdown
Below is a shutdown value that can be shown on the display. It is possible to configure ‘EIC
shutdown’ in the system setup to put the unit in a shutdown state and/or to activate relay outputs if
necessary. The shutdown state is present, until it disappears in the ECM module.
Shutdown list
AL Com. Alarm Red
