MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 33 THOMSON TECHNOLOGY
Measurement table (read only) function code 04h.
Scaling Addr Content Unit
J1939 ADEC MDEC
Description
601 EIC coolant level [%] 1/10 - - Coolant level
602 EIC fuel rate [L/h] 1/10 - - Fuel rate
603 EIC charge air press [bar] [psi] - - 1/100 Charge air press
604 EIC intake manifold 1
T (or EIC charge air T)
[deg] [F] 1/1 - 1/10 Intake manifold 1
temperature
605 EIC d.d. % torque [%] 1/1 - - Driver’s demand
engine - percent
torque
606 EIC actual % torque [%] 1/1 - - Actual engine -
percent torque
607 EIC acc. pedal pos. [%] 1/1 - - Accelerator pedal
position
608 EIC % load, c. speed [%] 1/1 - - Percent load at
current speed
609 EIC air inlet pressure [bar] [psi] 1/100 - - Air inlet pressure
610 EIC exhaust gas temp. [deg] [F] 1/10 - - Exhaust gas
temperature
611 EIC engine hours [H] 1/1 1/1 - ENGINE HOURS
612 EIC oil filter diff. press. [bar] [psi] 1/100 - - Oil filter diff press
613 EIC battery voltage [V] 1/10 1/10 - Keyswitch battery
potential
614 EIC fuel del. press. [bar] [psi] 1/100 1/100 - Fuel delivery
pressure
615 EIC oil level [%] 1/10 - - Engine oil level
616 EIC crankcase press. [bar] [psi] 1/100 - - Crankcase
pressure
617 EIC coolant pressure [bar] [psi] 1/100 - - Coolant pressure
618 EIC water in fuel [2 bits] 1/1 - - Water in fuel (1 =
Yes, 0 =NO)
619 Reserved - - - - -
620 Reserved - - - - -
621 Reserved - - - - -
622 Reserved
-
- -
-
623 EIC turbo oil temp. [deg] [F] 1/10 - - Turbo oil temp.
624 EIC trap inlet [bar] [psi] 1/100 - - Trap inlet
625 EIC Air filter diff press [bar] [psi] 1/1000 - - Air filter diff press
626 EIC Cool filter diff
press
[bar] [psi] 1/100 - - Cool filter diff
press
627 EIC Atm press [bar] [psi] 1/100 - - Atmospheric
pressure
628 EIC Ambient air temp [deg] [F] 1/10 - - Ambient air temp
[F/10]
