24 DCx camera
© 2010 Thorlabs
4.4
The status LED
The LED on the rear side of the DCU camera indicates whether:
The DCU camera is power supplied: LED lites up red (only USB-Board Rev. 2.0 or higher).
The DCU driver has been loaded and the camera is ready for operation: LED shines green
The status LED can also help you in case of trouble shooting by providing error codes, see
section trouble shooting
Figure 6 The Status LED (rev. 1.2)
Figure 7 The Status LED (rev. 2.0)
