THORLABS DCC1645C User Manual

404 DCx camera
© 2010 Thorlabs
10.1.5.2
DCU224x
Table 24 : Sensor specifications of the DCU 224x
Sensor type
CCD
Exposure mode
Electronic global shutter
Read out mode
Progressive scan
Resolution
1280 x 1024 Pixel
Optical sensor class
1/2 "
Exact sensitive area
5.95 mm x 4.76 mm
Exact optical sensor diagonal
7.6 mm, 0.3“
Pixel size
4.65 µm, square
Sensor name monochrome camera
Sony ICX205AL
Sensor name color camera
Sony ICX205AK
Pixel clock range
5 – 30 MHz
*1
Frame rate, freerun mode
15 fps
*2
Frame rate, trigger mode, 1ms exposure time
14 fps
*2
Exposure time in freerun mode
0.08 ms
*2
– 1460 ms
*3
Exposure time in trigger mode
0.08 ms
*2
– 10 minutes
*3
Binning
vertical
*4
Mode
Monochrome
Factor, maximum resolution, frame rate
2x, 1280 x 512 Pixel, 23 fps
Factor, maximum resolution, frame rate
4x, 1280 x 256 Pixel, 31 fps
Subsampling
-
AOI
horizontal, vertical
*4
Frame rate bei 320 x 240 pixel (CIF)
43 fps
Absolute image width, step width
16 – 1280 Pixel, 16
Absolute image height, step width, monochrome
120 – 1024 Pixel, 1
Absolute image height, step width, color model
120 – 1024 Pixel, 2
Position raster horizontal, monochrome
1
Position raster horizontal, color model
2
Position raster vertical, monochrome
1
Position raster vertical, color model
2
Gain
Monochrome model
Master
